螺旋輸送機是一種利用電機帶動螺旋回轉，推移物料以實現輸送目的的機械。它能水平、傾斜或垂直輸送，具有結構簡單、橫截面積小、密封性好、操作方便、維修容易、便于封閉運輸等優點。　　A screw conveyor is a mechanical device that uses an electric motor to drive a screw to rotate and move materials to achieve conveying purposes. It can transport horizontally, obliquely, or vertically, and has the advantages of simple structure, small cross-sectional area, good sealing, easy operation, easy maintenance, and convenient enclosed transportation.　　螺旋輸送機工作原理：　　當螺旋軸轉動時，由于物料的重力及其與槽體壁所產生的摩擦力，使物料只能在葉片的推送下沿著輸送機的槽底向前移動。物料的主要前進動力是來自螺旋葉片在軸向旋轉時將物料沿葉片切線方向向上和向前的作用力。　　When the spiral shaft rotates, due to the gravity of the material and the frictional force generated between it and the groove wall, the material can only move forward along the bottom of the conveyor groove under the push of the blades. The main forward force of the material comes from the force exerted by the spiral blades when rotating axially, which moves the material upwards and forward along the tangent direction of the blades.　　螺旋輸送機分類：【電話/微信咨詢：陳經理18068546632】　　螺旋輸送機從輸送物料位移方向的角度劃分，螺旋輸送機分為水平式螺旋輸送機和傾斜式螺旋輸送機兩大類型?！　rom the perspective of material displacement direction, screw conveyors are divided into two types: horizontal screw conveyors and vertical screw conveyors.　　傾斜式螺旋輸送機　　傾斜螺旋輸送機的螺旋體的轉速比普通螺旋輸送機的要高，加入的物料在離心力的作用下，與機殼間產生了摩擦力，該摩擦力阻止物料隨螺旋葉片一起旋轉并克服了物料下降的重力，從而實現了物料的傾斜輸送。該機輸送量小，輸送高度小，轉速較高，能耗大。特別適宜輸送流動性好的粉粒狀物料,主要用于提升物料，提升高度一般不大于8米?！　he rotation speed of the spiral body of a vertical screw conveyor is higher than that of a regular screw conveyor. The added material generates frictional force between the machine casing under the action of centrifugal force, which prevents the material from rotating with the spiral blades and overcomes the gravity of the material's descent, thus achieving vertical transportation of the material. This machine has a small conveying capacity, a small conveying height, high rotational speed, and high energy consumption. Especially suitable for conveying powder and granular materials with good fluidity, mainly used for lifting materials, with a lifting height generally not exceeding 8 meters.　　水平螺旋輸送機：　　當物料加入固定的機槽內時，由于物料的重力及其與機槽間的摩擦力作用，堆積在機槽下部的物料不隨螺旋體旋轉，而只在旋轉的螺旋葉片推動下向前移動，如同不旋轉的螺母沿著轉動的螺桿作平移運動一樣，達到輸送物料的目的。該機便于多點裝料與卸料，輸送過程中可同時完成混合、攪拌或冷卻功能。對超載敏感，易堵塞;對物料有破碎損耗，水平螺旋輸送機的結構簡單，便于安裝和維修以及故障處理。適用于水平或微傾斜(20o以下)連續均勻輸送松散物料?！　hen the material is added to a fixed machine slot, due to the gravity of the material and its frictional force with the slot, the material piled up at the bottom of the slot does not rotate with the spiral body, but only moves forward under the push of the rotating spiral blades, just like a non rotating nut moving along the rotating screw, achieving the purpose of conveying the material. This machine is convenient for multi-point loading and unloading, and can simultaneously complete mixing, stirring, or cooling functions during the conveying process. Sensitive to overload and prone to blockage; The horizontal screw conveyor has a simple structure and is easy to install, maintain, and troubleshoot due to material crushing and loss. Suitable for continuous and uniform conveying of loose materials horizontally or slightly inclined (below 20 o).　　螺旋輸送機應用范圍：　　螺旋機廣泛應用于各行業，如化工、建材、電力、冶金、煤礦炭、糧食等行業，適用于水平或傾斜輸送粉狀、粒狀和小塊狀物料，如煤礦、灰、渣、水泥、糧食等，物料溫度小于200℃。螺旋機不適于輸送易變質的、粘性大的、易結塊的物料。在混凝土攪拌站中,螺旋輸送機的作用得到了很好的體現?！　piral machines are widely used in various industries, such as chemical, building materials, electricity, metallurgy, coal mine charcoal, grain, etc. They are suitable for horizontal or inclined conveying of powdered, granular, and small materials, such as coal mine, ash, slag, cement, grain, etc., with material temperatures below 200 ℃. Spiral machines are not suitable for conveying materials that are prone to spoilage, high viscosity, and clumping. The role of screw conveyors is well demonstrated in concrete mixing plants.　　螺旋輸送機優點:【電話/微信咨詢：陳經理18068546632】　　具有橫截面尺寸小，結構簡單，密封性能良好，中間多點裝料和卸料，操作方便，成本較低等優點?！　t has the advantages of small cross-sectional size, simple structure, good sealing performance, multiple loading and unloading points in the middle, convenient operation, and low cost.　　公司在強化企業管理的基礎上，依靠科技進步提高技術含量，先進的生產加工設備，領 先的管理理念，高素質的員工團隊，有效的質量保障體系和完善的售后服務，為制造高品質的產品提供可靠的保證，極大的滿足了各行業的需求，深受廣大客戶的信賴?！　∥夜臼冀K堅持“質量第 一、用戶至 上”的宗旨，服務于社會，誠信于業界，竭誠歡迎世界各地的業界好友光臨指導，洽談合作。           《掃二維碼-添加 陳經理 微信-咨詢產品》　　On the basis of strengthening enterprise management, the company relies on technological progress to improve technological content, advanced production and processing equipment, leading management concepts, a high-quality staff team, an effective quality assurance system, and perfect after-sales service to provide reliable guarantees for manufacturing high-quality products, greatly meeting the needs of various industries, and deeply trusted by customers.　　Our company always adheres to the principle of "quality first, customer first", serves society, and is honest in the industry. We warmly welcome friends from all over the world to visit and guide us, and negotiate cooperation.
